Dense Zircon Brick

Dense Zircon Brick Introduction

Dense zircon brick as a kind of hot-sales refractory bricks for furnace application in Rongsheng factory manufacturing with applied to the bottom of the glass kiln pool, paving brick and kiln superstructure. Dense zircon bricks have good properties of excellent thermal shock stability and high temperature creep performance.There are high quality dense zircon refractory brick for sale cheap in RS Company can provide standard chrome brick size specification and category as well as competitive price & high grade quality refractory zircon brick products,other specification and size of zircon brick refractory according to customer requirements,welcome to contact us or email us for free quote or price list.

Dense Zircon Brick Properties

1. Zircon brick refractory have good thermal shock resistance

2. Zircon brick refractory have high temperature resistance

3. Zircon brick refractory have resistance to glass erosion

Dense Zircon Brick Specification



Dense Zircon Brick Application

1. Zircon brick refractory mainly used in the bottom of the alkali-free glass, borosilicate glass pool kiln, upper space brick, hook brick, gap brick, runner brick, thermocouple brick and observation hole brick.

2. Zirconium in refractories widely used in the bottom of glass kiln pool, paving brick and kiln superstructure,such as: arch brick, corner brick, chest wall brick, transition brick, temperature brick, observation hole brick.

3. Zircon fire brick used in the lining of the molten pool of glass kiln for melting glass fiber.

Dense Zircon Brick Manufacturing Process

Zircon refractory bricks are made of zircon as a main raw material, and an appropriate amount of a sintering additive is added.

1. The zircon raw material itself has no plasticity and decomposes at a high temperature,dense zircon brick is necessary to adopt a process measure suitable for the bonding agent, the particle size ratio and the firing condition in the production. Zircon refractory bricks should be used as raw materials for brick making. The mass fraction of Zro2 should be above 65%. The impurity part of zircon should be strictly controlled R2O, because R2o will not only reduce the decomposition temperature of zircon, but also affect the decomposition. The amount and viscosity of the glass phase are formed.

2. The zircon raw material has a very fine particle size and is directly made into fireproof zircon bricks, which is difficult in the process. In order to adjust the particle size composition of the ingredients and reduce the firing shrinkage, the zircon fire bricks is preliminarily compounded.

3. Zircon raw material is best to grind the zircon bricks before the mature material to promote sintering, reduce the sintering temperature, increase the mud plasticity. Such a raw zircon material can produce a clinker having a low water absorption rate and a high bulk density.

4. When soft clay is used as the binder, fire clay with high plasticity, high refractoriness and low sintering temperature should be used.

5. With the increase of fire clay water content, the refractoriness of density zircon bricks is significantly reduced, the load softening temperature is also reduced, the fire clay addition amount is increased from 5% to 15%, and the refractoriness of the refractory brick is reduced from 1750 °C to 1680 °C, load softening temperature. From 1700 ° C to 1600 ° C.

Zircon Brick Effect of the Amount of Fire Clay Added on the Firing Temperature

1.Reducing the amount of fire clay added is beneficial to improve the thermal shock resistance of density zircon bricks. The entire clinker has a higher thermal shock resistance than a product with a portion of the clinker material.

2.When a large amount of clay zircon brick is added, a high temperature liquid phase is formed, and a high temperature liquid phase is filled around the zircon bricks to promote sintering and to be easily densified.

3.During the refractory zircon bricks firing process, the liquid phase penetrates into the cracked zircon particles, adding a new reaction surface and promoting the decomposition of zircon. More liquid phase reduces refractoriness and load softening temperature.

4.When the temperature changes, there is a corresponding large volume change. When the temperature changes, there is a corresponding large volume change, which makes the fired zircon bricks less resistant to thermal shock.

Dense Zircon & Low Porosity Brick Produce

Zirconium-density, low-porosity zircon bricks are generally made of a fine powder, cast or isostatically pressed, fired at a high temperature.

❉The biggest feature of isostatic pressing is that the parts of the zircon refractory bricks mud are uniformly pressed and the pressure is high. The obtained body has high density and uniform density, so that the deformation and shrinkage of the body during the firing process are greatly reduced. A blank formed by a general molding method may be formed, stress may be generated due to a difference in density to cause cracking.

❉The isostatic press molding has simple pressurization operation, convenient molding pressure adjustment, simple rubber or plastic mold for molding, convenient molding pressure adjustment, and can be used repeatedly. The temporary binder can be used or not in the mud material, and the billet can be improved. Refractory zircon bricks body density, high-quality compact fireproof zircon bricks, generally formed by a wet bag method isostatic pressing machine, forming pressure is 180~250Mpa.

❉Zircon sand is used as raw material, and then vibrating mill, ball mill crushing, mud pressure casting molding, high-temperature firing of dense zircon brick.

❉Zirconium bricks bulk density (g/cm3) is 3.8~4.0, 4.0~4.2. The apparent porosity (%) is 5~10 and 0.5~2.0, respectively. Zirconium bricks product has been used in many glass factories and has good effect.

Dense Zircon Brick Supplier in RS Factory

RongSheng refractory factory has been engaged in refractory material industry for more than 20 years.RS refractory bricks company have a excellent technological team and have the professional sales team.

Rongsheng firebricks manufacturer can provide specification and category as well as competitive price & high-grade quality bricks products.Rongsheng firebricks factory can provide refractory high chrome bricks density, standard chrome brick size according to client requirements.
